#555 BOBST 3 COLOR FLAT DIE CUTTER
MACHINE CAPABILITIES
updated 3/8/21
General
- Blank width:
- Min: 6”
- Max: 50 1/8”
- Blank length:
- Min: 12” (if less ask Production)
- Max: 65 7/8”
- Corrugated Blank Width:
- Min: 20 ½”
- Max: 51 1/8”
- Corrugated Blank Length:
- Min: 27 9/16”
- Max: 66 7/8”
- Printing:
- 3 color
- 66” cylinder
- Click here for additional printing information: Print Specifications
- Trim
- Lead and trail trim 1”, side trim ¾”
2 bundle breakers, one for each direction. Ask for odd shaped items
- 6" min through machine
- 7" min across machine
- To see production speed in Crosswise direction click here: Breaker - Crosswise
- To see production speed in Longitudinal direction click here: Breaker - Longitudinal
Minimum slot width 3/16" for single wall and 3/8" for double wall
Can do matrix scoring.
If printing only and blank size is larger than max corrugator size, ask production.
Cannot run Poly Coated boxes or sheets
NOTE: Width refers to direction through the machine
