#218 FALCON FLEXO FOLDER GLUER

updated 5/8/2024

General

• Blank width:
  • Min:     9 ¹/₁₆”
  • Max:    35 ¼” Can go up to 36 ⁹/₁₆” with skid feed (½ machine speed)
• Blank length:
  • Min:     29 ¾”
  • Max:    95 ¹/₁₆”

• Minimum panel sizes:
  • If joint is on the large panel:
    • 7 ⁷/₈” length
    • 6 ½” width (exception: 4 ½” width if length + width >= than 11 ³/₁₆”)
    • 3 ¹⁵/₁₆” depth  (exception: 2” depth with extended glue tabs)
  • If joint is on the small panel:
    • 7 ⁷/₈” length
    • 7 ⁷/₈ “ width
    • 3 ¹⁵/₁₆” depth  (exception: 2” depth with extended glue tabs)
  • Click here for additional size information: Panel Dimensions

• Maximum depth 18 ¼”  (exception: 22 ½” max if width panel <= 14” for RSCs and 7 ¹/₈” for FOLs)
• Maximum slot: 9 ⁵/₈” (exception: 7 ¹/₈” if depth > 22 ½”)
• Outside glued cartons take extra time to setup. This setup time is calculated in the estimate.

• Minimum panel sizes when not gluing mfg. joint.
  • 7 ⁷/₈” length
  • 3 ½” width
  • 3 ¹⁵/₁₆” depth (exception: 2” depth with extended glue tabs)
  • No minimum blank length, along as min. panel dimensions are met.

• Maximum mfg. joint width 2”
• ³/₈” slots
• Hold Down Tabs – Can do, but tabs must be towards lead edge of machine.

• Die cut section:
  • 36.6” cylinder.
  • Maximum cutting rule straight across machine: 19 ¹¹/₁₆”

• Printing:
  • 3 color
  • 36.6” cylinder
  • 250 line anilox rolls
  • Max 45 line, 50% screen
  • Max length printed 88 ½”
  • Add ¼” length trim if print goes over edge of blank.


  • Click here for additional printing information: Print Specifications

• Unitizing
  • Unit size cannot exceed 58” in either direction

• Cannot run Poly Coated boxes or sheets
